1SCA022627R3170
160A gG DIN fuse size 0 500V dual ind (OFAF0H160)
Trade Price
£12.96
Per
1
Unit
EA
Pack Quantity
1
Information
DIN-type 500V Fuses - HRC fuse links, gG, universal fuses OFAF_H_, = 500 V * Part number: OFAF0H160 * The type code includes one fuse link. * Dual indication.
Technical Specifications
Minimum Order Quantity
3 piece
Customs Tariff Number
85361090
Country of Origin
Hungary (HU)
Product Net Width
40 mm
Product Net Height
125 mm
Product Net Depth / Length
60 mm
Product Net Weight
0.21 kg
Power Loss
14.6 W
Fuse Size
NH0
Fuse System
DIN
Standards
IEC 60269
Fuse Type
gG
Rated Current (In)
160 A
Rated Voltage (Ur)
500 V
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Package Level 1 Units
3 piece
Package Level 1 Width
40 mm
Package Level 1 Depth / Length
125 mm
Package Level 1 Height
60 mm
Package Level 1 Gross Weight
0.6615 kg
Package Level 1 EAN
6417019205656
Object Classification Code
F
ETIM 7
EC000055 - Low Voltage HRC fuse
ETIM 8
EC000055 - Knife blade fuse
ETIM 9
EC000055 - Knife blade fuse
eClass
V11.1 : 27142005
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland)
3112896
Document Links
Datasheet
