1SCA022660R9930
800A gG DIN fuse size 4 690V dual ind (OFAA4AGG800)
Trade Price
£250.09
Per
1
Unit
EA
Pack Quantity
1
Information
DIN-type 690V Fuses - HRC fuse links, gG, universal fuses OFAA_GG_, = 690V * Part number: OFAA4AGG800 * The type code includes one fuse link. * Dual indication on fuse link sizes 2 and 3.
Technical Specifications
Minimum Order Quantity
1 piece
Customs Tariff Number
85361090
Country of Origin
Hungary (HU)
Product Net Width
89 mm
Product Net Height
200 mm
Product Net Depth / Length
119 mm
Product Net Weight
2 kg
Power Loss
65.0 W
Fuse Size
NH4a
Fuse System
DIN
Standards
IEC 60269
Fuse Type
gG
Rated Current (In)
800 A
Rated Voltage (Ur)
690 V
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Package Level 1 Units
1 piece
Package Level 1 Width
110 mm
Package Level 1 Depth / Length
230 mm
Package Level 1 Height
160 mm
Package Level 1 Gross Weight
2.1 kg
Package Level 1 EAN
6417019212999
Object Classification Code
F
ETIM 7
EC000055 - Low Voltage HRC fuse
ETIM 8
EC000055 - Knife blade fuse
ETIM 9
EC000055 - Knife blade fuse
eClass
V11.1 : 27142005
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland)
3123427
Document Links
Datasheet
