Minimum Order Quantity

3 piece

Customs Tariff Number

85361090

Country of Origin

Hungary (HU)

Product Net Width

40 mm

Product Net Height

135 mm

Product Net Depth / Length

66 mm

Product Net Weight

0.4 kg

Power Loss

14.6 W

Fuse Size

NH1

Fuse System

DIN

Standards

IEC 60269

Fuse Type

gG

Rated Current (In)

160 A

Rated Voltage (Ur)

690 V

RoHS Status

Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019

Package Level 1 Units

3 piece

Package Level 1 Width

95 mm

Package Level 1 Depth / Length

140 mm

Package Level 1 Height

70 mm

Package Level 1 Gross Weight

1.26 kg

Package Level 1 EAN

6417019223841

Object Classification Code

F

ETIM 7

EC000055 - Low Voltage HRC fuse

ETIM 8

EC000055 - Knife blade fuse

ETIM 9

EC000055 - Knife blade fuse

eClass

V11.1 : 27142005

WEEE Category

5. Small Equipment (No External Dimension More Than 50 cm)

E-Number (Finland)

3123113
