1SCA022701R0960
355A gG DIN fuse size 2 690V dual ind (OFAA2GG355)
Trade Price
£25.48
Per
1
Unit
EA
Pack Quantity
1
Information
DIN-type 690V Fuses - HRC fuse links, gG, universal fuses OFAA_GG_, = 690V * Part number: OFAA2GG355 * The type code includes one fuse link. * Dual indication on fuse link sizes 2 and 3.
Technical Specifications
Minimum Order Quantity
3 piece
Customs Tariff Number
85361090
Country of Origin
Hungary (HU)
Product Net Width
50 mm
Product Net Height
150 mm
Product Net Depth / Length
72 mm
Product Net Weight
0.63 kg
Power Loss
31.5 W
Fuse Size
NH2
Fuse System
DIN
Standards
IEC 60269
Fuse Type
gG
Rated Current (In)
355 A
Rated Voltage (Ur)
690 V
RoHS Status
Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Package Level 1 Units
3 piece
Package Level 1 Width
125 mm
Package Level 1 Depth / Length
55 mm
Package Level 1 Height
80 mm
Package Level 1 Gross Weight
1.9845 kg
Package Level 1 EAN
6417019223926
Object Classification Code
F
ETIM 7
EC000055 - Low Voltage HRC fuse
ETIM 8
EC000055 - Knife blade fuse
ETIM 9
EC000055 - Knife blade fuse
eClass
V11.1 : 27142005
WEEE Category
5. Small Equipment (No External Dimension More Than 50 cm)
E-Number (Finland)
3110202
Document Links
Datasheet
