Short description

Flexible compact DALI solution designed for conference rooms, training rooms and classrooms

Long description

Flexible compact DALI solution designed for conference rooms, training rooms and classrooms Surface-mount version High-sensitivity occupancy detector with the capability to address up to 64 DALI electronic ballasts (ECG) automatically, with segmented control via 4 groups Quick commissioning and maintenance processes with smartphone/tablet app (Android, iOS) - PC tool not required 3 lighting zones: A for main lighting with segmented constant light regulation via 3 DALI groups and offset control, B for lectern or blackboard lighting via separate DALI group, C for lectern or blackboard lighting by integrated relay 3 lighting zones: A for main lighting with segmented constant light regulation via 3 DALI groups and offset control, B for lectern or blackboard lighting via separate DALI group, C for lectern or blackboard lighting by integrated relay High performance switching relay with various operating modes, e.g. cutoff function for DALI ECG, HVAC, blackboard lighting etc. Manual switching and dimming available with conventional push buttons Detection area can be extended with up to four Slave devices of type PD4-S-DAA4G Full range of functions can only be activated with the B.E.G. IR-Adapter and a smartphone or tablet (Android, iOS)

EAN code

4007529927432

Name of manufacturer

B.E.G.

Special treatment class

NONE

Minimum quantity

1

Maximum quantity

1

Volume (m³)

0.002214

Gross weight (kg)

0.500

Length (m)

0.150

Width (m)

0.123

Depth (m)

0.123
