IP65, suitable for use in bathrooms (internal use only)

Ultra fast press-fit termination

Enclosed can design for maximum fire safety

High quality aluminium bezel

Triac dimmable available (recommended dimmer list on JCC website)

Product Group

LED - Recessed

Product Range

FGLED

Trade Name

FGLED

Light Source

LED

Light Source Features

Warm White

Lighting Product Type

Fired Rated Downlights

Product Shape

Round

Additional Information

Cut out Ø72-74mm for 12.5mm thick 30minute ceilings 79-81mm for 30mm thick 60-90 minute ceilings

Mounting

Recessed

Product Weight

0.3Kg

Color Finish

White

Recommended Product Location

Suitable for indoor use

Minimum Void Requirement

75mm

Method Of Fix

Spring Clips(provided)

Product Aperture Size

74mm

IP Rating

IP65

Environment

Indoor

Suitable For Zones

Zone 1

Luminaire Accessories

Concealer ring (JC94183), Convertor plate (JC94180)

Warranty

2 years standard warranty extends to a 5 year commercial warranty or 10 year domestic warranty when registered within the first year of purchase (See Website for terms and conditions)

Dimming Protocol Compatibility

Triac

Driver Manufacturer

Seoul

LED Manufacturer/Type

5050/Seoul

Voltage Rating

220-240

Primary Running Current

0.03A

Operating Frequency (Hz)

50/60Hz

Luminaire Circuit Wattage

4.8W

Sec - Voltage (V)

177V~

Class

Class I, Must be earthed

EMC Compliant (EN55015)

Yes

Power Factor Correction

0.7

Input Electrical Connections

Live, Earth, Neutral (Press fit large loop in / loop out terminal)

Dimmable

Yes

Max Luminaire Ambient Temp.

40°C

Max Driver/Ballast Ambient Temp.

68°C

Thermal Cut Out

150°C

Insulation Coverage

Can be loosely covered with mineral wool insulation

Minimum Free Air Space

At least 50mm above and to the sides

Energy Rating

A+

Actual Lumen Output

320

Lumens Per Circuit Watt

67 lm/W

LED Life (Hours) (L70)

50,000

Hours life stated is an indication of expected L70 chip and light output calculations when operating in optimum conditions. Product warranty period supports the full product during the term given. The L70 hours expectancy is not correlated with the full product warranty term, nor is it a representation of lumen depreciation during the warranty period.

Color Rendering Index

80-89

CRI: Ra

80

Correlated Color Temperature

3000K

Light Distribution Detail

38-degree

LOR (Light Output Ratio) %

100%

Photometry Available

Yes, on request

Primary Material

Steel

Lens

38° power lens

Heat Sink

Aluminium

Driver Housing

Polycarbonate

Rim Or Attachment

Die-cast aluminium

Luminaire Carton Dimensions

120mm x 100mm x 90mm

Quantity Per Outer Carton

20

Bar Code EAN Number

5052544022609(CH) / 505244022616(CH) / 5052544022623(WH)

Packaged Weight

0.4Kg

Listings

CE

Listings

Fire Rating

Manufactured In Accordance To

BS EN 00598-2-1

CE Marked

Meets all European Standards for CE Mark

Batch Coded

Yes

Certificate Of Conformity

Yes, available on request

Accredited Members

LIA, ISO9001:2015, ISO14001:2015
