KBTN70LS3/SCT
NIVA II batten, CCT switching, twin output, 70W, 6ft
Trade Price
POA
Per
1
Unit
Each
Pack Quantity
1
Information
The Niva II LED batten utilises high performance LEDs to offer outstanding lumen efficiency. The battens have a switchable CCT and are suitable for a wide range of applications including warehouses, factories and garages. Also has the option to install an emergency module and microwave sensor. High efficiency up to 130lm/W Optional plug-in emergency module available For single and twin tube batten replacement 20mm Conduit entry BESA box fitting points Switchable CCT (3000K/4000K/6000K)
Technical Specifications
Input Voltage Supply
220-240Vac 50/60Hz
Lumens Output Maximum (lm)
9,200
CCT (K)
4,000
CCT Words
Cool White
Ambient Temperature Range (°C)
-20°C to 50°C
Blue Light Hazard
RG1
Default Setting
4000K at 70W
Dimensions (L x W x D) (mm)
1734x61x71
Glow wire temperature(°C)
650
IK Rating
IK08
Inrush Current (peak/duration) (A)
25.1A/358µs
Installation Area
Internal
L70B50 Lifetime (h) @Ta 25 °C
60,000
L80B10 Lifetime (h) @Ta 25 °C
60,000
L90 Lifetime (h) @Ta 25 °C
48,000
Light Source Supply
45Vdc 1400mA
Maximum Current Draw (mA)
317
Nominal Lifetime (h) @Ta 25 °C
50,000
Protection Rating
Class I
Rated Power (W)
70
Weight
2Kg
IP Rating
IP20
Power Factor
0.96
User Settable Colour Temperature
3000k, 4000k, 6000k
Maximum Wattage
70
Maximum Efficiency (lm/W)
131
UME/EME Emergency Luminous Flux (lm)
600
Document Links
Datasheet
Features
Switchable CCT (3000K/4000K/6000K)
High efficiency
Optional plug-in emergency module available
For single and twin tube batten replacement
20mm Conduit entry
Specifications
Barcode
5060063427263
