A table of pre-selectable adjustable programs are offered - covering all of the low rate electricity tariffs, including Economy 7, Economy 10 & Eco 20:20 times. Turn the Installer Switch to the program of choice (refer to Installation and User Instructions). Adjustment is possible to the preset times enabling the program periods to be reduced or cancelled as required. The review button allows ON/OFF times to be checked & there is automatic GMT/BST changeover.

There is a 0.5 hour, 1 hour & 2 hour boost function with a digital display countdown clock, allowing the user to clearly see boost times. There is also a programmable boost function for further end user convenience; this program is deliberately limited to a maximum of 2 hours, meaning expensive electricity is not being wasted during peak times.

Suitable for single, dual and twin immersion elements

Pre-set programs for use with low rate tariffs

Direct upgrade to Horstmann E7 & E7Q and Sangamo Q7 controllers

24 hour electronic timer

Supply voltage

230V a.c.

Supply Frequency

50-60 Hz

Frequency

50/60Hz

Timing accuracy

+/- 0.5 sec per day at +23°C

Power consumption

1.2W

Shock protection

Class 1

Conforms to

BS EN60730

Contact rating

13A Resistive 230V Suitable for immersion heaters up to 3kW

Contact type

Micro-disconnection on control. Disconnection to immersion heater(s) via double pole rocker switch

Enclosure protection

IP30

Dimensions

169 x 114 x 60mm deep (excluding rocker switch & buttons)

Program cycle

24 Hours

Changeover contacts voltage free inductive load (cos = 0.6)

100

Operation temperature

0°C to 35°C

Memory reserve

3 years

Live parts

Enclosed
