An electronic controller offering a maximum of 3on & 3off each day according to the programming cycle selected.

One of the main benefits of the Powersaver Select product is its standard size. This is common to all models, which fit directly onto a single gang pattress box.

24 hour, 5/2 day & 7 day electronic timer

Up to 3 program operations per day

30 mins, 1 hour and 2 hour boost function

Fits directly onto a single gang pattress box

Supply voltage

230V a.c.

Supply Frequency

50-60 Hz

Display

LCD

Power consumption

10VA Maximum

Live parts protection

This unit is totally protected by the enclosure

Dirt and moisture protection

IP00

Shock protection

Class 1 (this unit must be connected to earth)

Contact rating

16A Resistive 240Vac

Resolution of programs

10 Minutes

Fixing

Single Pattress - Surface and Flush Mounting

Changeover contacts voltage free inductive load (cos = 0.6)

100

Case material

Polycarbonate

Type of action type

Type 1B

Temperature rating

T35

Operation temperature

0°C to 35°C

Memory reserve

4 Hours - when on power for previous 12 hours

Program settings

Max 3 On/Off Operations each day according to program cycle selected: 1. Daily (24 Hour) Cycle - All days programmed the same 2. Weekly (5/2 Day) Cycle - Mon-Fri are programmed the same. Sat- Sun have separate set of programs. 3. 24/7 (7 Day) Cycle Each day is independently programmable.

Boost settings

User selectable - 0.5, 1 or 2 hours

Control pollution category

Normal
