ASTRO5
Astro 5W 4000K IP20 221mm Link Light
Trade Price
£26.33
Per
1
Unit
EACH
Pack Quantity
1
Document Links
Datasheet
General Details
Finish
White Body c/w Opal Diffuser
Product Weight
0.39kg
Overall Dimensions
221mm X 23mm X 37mm
Carton Weight / Material
1.00 kg / Cardboard
Packaging & Labelling Guidelines
Saturn LED.eu - Generic labelling
Bar Coding
Saturn LED coding in accordance with EAN-12 & ITF-14
IP Rating
IP20
Energy Rating
A* - (Very Low Energy)
Light Source
Rated Wattage
5W
Lumens
300
Lumens Per Watt
67
Recommended Product Location
Interior Commercial / Domestic Lighting
Light Source Brand
Epistar LED Chips
Colour Temperature
4000K
CRI Ra
Ra > 70
Lifespan
30,000 Hours
Lamp Working Temperature
<50°C
Beam Angle
120°
Photometric Data
Visit www.saturnled.eu for full Photometric files
Lamp Code
N/A
Electrical
Voltage
220-240V. 50 / 60Hz. AC.
Total Running Wattage (W)
98 W
Electrical Classification
Class I
Cabling Electrical Connections
Screw fix in terminal block
LED Driver
Osram Electronic ballast
Battery
Test
Battery Sizes
Test
Installation
Distance from Illuminated Object
0.5m
Light Throw Distance
Test
Method of Fix
Surface mounted on a suitable substrate.
Recommended Working Temperature
Minimum Temp -10°C to Maximum Temp + 40°C
Instruction Sheet
Supplied with product
Origin & Markets
Country of Manufacture
Designed & tested in Europe - Manufactured in China
Intended Market
Europe, Middle East & Australia 220 - 240Volt
Materials
Main Housing Material
Steel
Fixings Main Housing
Steel
Front Shield
Clear PC
Approvals
Warranty
3 Year Warranty - For more information go to www.saturnled.eu/warranty
Marks & Symbols
CE -- SELV -- RoHS -- EMC -- WEEE
Quality Assurance System
SaturnLED quality assurance to ISO9001:2008
Certificate of Conformity
Available on request - technical@saturnled.eu
Manufactured in Accordance to
British Standard - BS EN 60598 - 2 - 1
