Range

PowerLogic

Product name

CT

Product or component type

Current transformer

Secondary current

5 A

Accuracy class

Class 0.5 at 2 VA Class 1 at 2.5 VA Class 3 at 3.5 VA

[In] rated current

100 A

current transformer type

Tropicalised for cable

current transformer ratio

100/5

[Ith] conventional free air thermal current

6 kA

dynamic withstand current

2.5 Ith

Maximum safety factor

5

[Ue] rated operational voltage

< 720 V AC 50/60 Hz

[Ui] rated insulation voltage

3 kV

Mounting mode

By screws Clip-on

mounting support

Mounting plate DIN rail

Width

44 mm outside:

Height

65 mm outside:

Depth

30 mm frame: 37 mm total:

Diameter

21 mm

Net weight

0.19 kg

[Uimp] rated impulse withstand voltage

3 kV

Electrical insulation class

Class B

Cable outer diameter

21 mm

Sealing

With

standards

VDE 0414 IEC 61869-2

product certifications

EAC CE

IP degree of protection

IP20

Relative humidity

0…95 %

Ambient air temperature for operation

-25…60 °C

Unit Type of Package 1

PCE

Number of Units in Package 1

1

Package 1 Height

5.600 cm

Package 1 Width

5.600 cm

Package 1 Length

8.400 cm

Package 1 Weight

192.000 g

Unit Type of Package 2

S02

Number of Units in Package 2

50

Package 2 Height

15.000 cm

Package 2 Width

30.000 cm

Package 2 Length

40.000 cm

Package 2 Weight

9.864 kg

Unit Type of Package 3

P12

Number of Units in Package 3

400

Package 3 Height

27.500 cm

Package 3 Width

80.000 cm

Package 3 Length

120.000 cm

Package 3 Weight

88.800 kg

Warranty

18 months
