Catalogues Trade Price List01/01/2024

CataloguesSiemensPower Breakers3VA27800 A

3VA2780-1AA13-0AA0

3VA2780-1AA13-0AA0 800A Four Pole Switch Disconnector

£2,125.52

EACH

3VA2780-1AA13-3AA0

3VA2780-1AA13-3AA0 fixed-mounted sw. disconnector frame 1600; with RTC and 4AUX Icu=55kA @ 415V, 4-pole, left SD100; In=800A without overload protection w/o short-circuit protection nut keeper kit No communication connection, no measurement function Motorized operating mechanism 100...130 V AC/DC incl. S21 spring energy store signaling switch With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,713.67

EACH

3VA2780-1AC02-1BA1-Z

3VA2780-1AC02-1BA1-Z fixed-mounted molded case circuit breaker frame 1600; with RTC and 4AUX trip alarm switch S24; Icu "M" Icu=55kA @ 415V, 3-pole ETU350, LSI, In=800A rotary coding switch Ir=320...800A Isd=1...10xIn, Ii=1.5...15xIn N conductor protec. adjustable opt. w. ext. CT; up to 200% rear horizontal connection No communication connection, no measurement function Motorized operating mechanism 24...30 V AC/DC incl. S21 spring energy store signaling switch With electr. and mech. calling Switch-on solenoid (CC) 24 V AC/DC without 2nd auxiliary release with 1st auxiliary release, ST Shunt release 24 V AC/DC K50= Ready indicator RTC auxiliary switch as version 24 V DC digital signal K51 Auxiliary current switch AUX 4 CO as version 24 V DC digital signal K53= Tripped signaling switch S24 as version 24 V DC digital signal S43= Interlock set for mechanical ON and/or OFF, padlock D=7 mm, on the operator panel S57= Pre-installed extension kit for external accessories Rear panel mounting (lateral shoulder modification) T30= Door sealing frame IP30 for fixed-mounted circuit breaker

£3,604.03

EACH

3VA2780-2AC13-0AA0

3VA2780-2AC13-0AA0 800A Four Pole Push Button MCCB

£3,269.54

EACH

3VA2780-5AA11-0AA0

3VA2780-5AA11-0AA0 fixed-mounted sw. disconnector with handle frame 1600; 4AUX Icu=55kA @ 415V, 4-pole, left SD100; In=800A without overload protection w/o short-circuit protection rear vertical connection No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,150.46

EACH

3VA2780-5AA13-0AA0

3VA2780-5AA13-0AA0 fixed-mounted sw. disconnector with handle frame 1600; 4AUX Icu=55kA @ 415V, 4-pole, left SD100; In=800A without overload protection w/o short-circuit protection nut keeper kit No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£1,879.39

EACH

3VA2780-5AA23-1AA0

3VA2780-5AA23-1AA0 fixed-mounted sw. disconnector with handle frame 1600; 4AUX Icu=55kA @ 415V, 4-pole, right SD100; In=800A without overload protection w/o short-circuit protection nut keeper kit No communication connection, no measurement function With trip alarm switch TAS and trip alarm switch S25 With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£1,952.29

EACH

3VA2780-5AB03-0AA0

3VA2780-5AB03-0AA0 fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "M" Icu=55kA @ 415V, 3-pole ETU320, LI, In=800A rotary coding switch Ir=320...800A Ii=1.5...15 x In N conductor protec. adjustable opt. w. ext. CT; up to 200% nut keeper kit No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£1,933.61

EACH

3VA2780-5AB05-0AA0

3VA2780-5AB05-0AA0 fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "M" Icu=55kA @ 415V, 3-pole ETU320, LI, In=800A rotary coding switch Ir=320...800A Ii=1.5...15 x In N conductor protec. adjustable opt. w. ext. CT; up to 200% straight bus connector extended No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,138.42

EACH

3VA2780-5AB13-0AA0

3VA2780-5AB13-0AA0 fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "M" Icu=55kA @ 415V, 4-pole, left ETU320, LI, In=800A rotary coding switch Ir=320...800A Ii=1.5...15 x In N conductor protec. adjustable OFF, 50%, 100%, 200% nut keeper kit No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,596.22

EACH

3VA2780-5AC03-0AA0-Z

3VA2780-5AC03-0AA0-Z fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "M" Icu=55kA @ 415V, 3-pole ETU350, LSI, In=800A rotary coding switch Ir=320...800A Isd=1...10xIn, Ii=1.5...15xIn N conductor protec. adjustable opt. w. ext. CT; up to 200% nut keeper kit No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release K52= Auxiliary current switch AUX 2 CO + 2 CO Variant 2x 400 V AC + 2x 24 V DC S57= Pre-installed extension kit for external accessories Rear panel mounting (lateral shoulder modification)

£2,094.73

EACH

3VA2780-6AC13-0AA0

3VA2780-6AC13-0AA0 fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "H" Icu=85kA @ 415V, 4-pole, left ETU350, LSI, In=800A rotary coding switch Ir=320...800A Isd=1...10xIn, Ii=1.5...15xIn N conductor protec. adjustable OFF, 50%, 100%, 200% nut keeper kit No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,939.57

EACH

3VA2780-6AC31-0AA0-Z

3VA2780-6AC31-0AA0-Z draw-out molded case circuit breaker w. handle with guide frame and PSS frame 1600; 4AUX and trip alarm switch S24; Icu "H" Icu=85kA @ 415V, 3-pole ETU350, LSI, In=800A rotary coding switch Ir=320...800A Isd=1...10xIn, Ii=1.5...15xIn N conductor protec. adjustable opt. w. ext. CT; up to 200% rear vertical connection No communication connection, no measurement function Without additional alarm switch assembly With mechanical calling without 2nd auxiliary release without 1st auxiliary release T30= Door sealing frame IP30 for slide-in circuit breaker

£3,367.25

EACH

3VA2780-7AB03-2AA0

3VA2780-7AB03-2AA0 fixed-mounted molded case circuit breaker w. handle frame 1600; 4AUX and trip alarm switch S24; Icu "C" Icu=110kA @ 415V, 3-pole ETU320, LI, In=800A rotary coding switch Ir=320...800A Ii=1.5...15 x In N conductor protec. adjustable opt. w. ext. CT; up to 200% nut keeper kit No communication connection, no measurement function With two leading auxiliary switches S26 Standard 400 V AC With mechanical calling without 2nd auxiliary release without 1st auxiliary release

£2,386.00

EACH
